All in One Interactive Display Whiteboard (DB) | ||||
Screen Size | 65"/75"/85"/86"/98"/100" | |||
Display | ||||
Frame | Frame | Aluminum Alloy Frame + Metal Back cover | ||
Display | Screen | DLED Backlight Display | ||
Resolution | 3840*2160 | |||
Lifespan | >30000H | |||
Ratio | 16:9 | |||
Color Gamut | 72% | |||
Viewing Angle | 178° | |||
Glass | Mohs 7 Explosion-proof Tempered Glass | |||
Brightness | 350 cd/㎡ | |||
Touch | Touch Technology | Infrared Touch | ||
Touch Point | 10 Points Touch | |||
Object Recognition(Min) | 2mm | |||
Response Time | 1ms | |||
Accuracy | ±2mm (above 90% touch area) | |||
Android OS | CPU | ARM A55 Quad Core | ||
GPU | Mali-G31 | |||
RAM | 4 GB | |||
Memory | 32 GB | |||
Operation System | Android 9.0 | |||
Front | Button | 1 Front POWER Button | ||
Language | OSD | Chinese, English and other language | ||
Camera & Microphone | ||||
Camera & Microphone | Camera | Top 8 Million Pixel / Field of View 73° | ||
Microphone | 4 Element Array High Sensitive Microphone 10m pickup pick-up distance Dual Track Stereo Speaker System | |||
Input & Output | ||||
Input & Output | LAN Input | 1 Rear | ||
HDMI Input | 3 (2 Rear / 1 Front) | |||
USB3.0 | 2 (1 Rear / 1 Front) | |||
USB TOUCH | 2 (1 Rear / 1 Front) | |||
VGA | 1 Rear | |||
Audio Input | 1 Rear | |||
RS232 | 1 Rear | |||
SPDIF | 1 Rear | |||
TV Input | 1 Rear | |||
TF Card | 1 Rear | |||
Headphone Output | 1 Rear | |||
DP | 1 Rear | |||
YPBPR | 1 Rear | |||
CVBS | 1 Rear | |||
USB 2.0 Type-A | 3 (2 Rear / 1 Front) | |||
USB 2.0 Type-C | 1 Rear | |||
Wi-Fi | 2.4GHz / 5GHz | |||
OPS | ||||
OPS 80pin (option） | CPU/RAM/ROM （option） | Intel I3/4G/128GB Intel I5/8G/128GB Intel I7/8G/128GB WIN 7 /WIN 10 | ||
Speaker | Speaker | Front Built-in Speaker 2*10W / 2*15W | ||
Power | ||||
Power Consumption | 240W ~ 700 W | |||
Power Supply | AC 180-240V 50/60Hz | |||
Dimension & Weight | ||||||||
Inch | Dimension (net) L * H * W (mm) | Dimension (box) L * H * W (mm) | Weight (net)(kg) | Weight (box)(Kg) | ||||
65" | 1498 x 918 x 96 | 1660 x 1065 x 225 | 45 | 59 | ||||
75" | 1723 x 1044 x 99 | 1875 x 1185 x 225 | 58.5 | 73.5 | ||||
85" | 1965 x 1180 x 99 | 2115 x 1325 x 225 | 77 | 95 | ||||
86" | 1965 x 1180 x 99 | 2115 x 1325 x 225 | 77 | 95 | ||||
98" | 2212 x 1305 x 106 | 2435 x 1490 x 275 | 92 | 125 | ||||
100" | 2275 x 1363 x 120 | 2435 x 1490 x 275 | 107 | 141 | ||||
